Model

DLT-101T

LCD Display

10.1"LED

Max. Resolution

1280 x R.G.B.x800

Display Area

227.42(H) x 147.99(V) mm

Display Color

262K

Contrast Ratio

600: 1(Typical ,Perpendicular)

Brightness

350cd/m 2

Response Time

10 / 30ms (tf/tr)

Viewing Angle

Wide Viewing Angle : 160/120

Input Signal

R/G/B Analog

Scan Frequency

Horizontal: 31.5 to 60KHz / Vertical : 55 to 74Hz

Lamp Life Time

50,000hrs(Typ.)

Compatibility of VGA

VESA VGA / SVGA / DVI

AC/DC Adapter

Input : AC 100~240,50~60HZ; Output: DC 12V/ 3A

Power Consumption

22W( Max.)/ Stand by under 4W

Operation Environment

Temperature 0~40°C ,Humidity : Less than 85%

OSD Control Button

Power, Auto, Menu / Enter, Up, Down

Optional

Resistive Touch screen / true Flat Projected Capacitive Touch Screen

Volume

239mm (W)* 158mm(H)* 38mm(D)

Mounting

VESA 75mm x 75mm /  100mm x100mm

Net Weight

1.1kg

Color

Black
